CAPACITIES TO
315 GPM (19.9 LPS)
SOLIDS HANDLING
2" (50.8 mm)
LIQUIDS HANDLING
Raw unscreened sewage, fibrous wastewater, effluent, storm water
INTERMITTENT LIQUID TEMP.
Up To 140°F (60°C)
WINDING INSULATION TEMP CLASS F
311°F (155°C)
MOTOR ELECTRICAL DATA
3450 RPM 3 – 5 HP, 200/230V, 1Ø, 60 Hz 3 – 7½ HP, 200/230/460/575V, 3Ø, 60 Hz
STD. THIRD PARTY APPROVALS
CSA
OPTIONAL APPROVALS
FM Class 1, Groups C & D (3RHX only)
SPECIFIC GRAVITY
.9 – 1.1
HORIZONTAL DISCHARGE
3" (76 mm)
FLANGED CENTERLINE
125 lb. ANSI
MOTOR HOUSING, SEAL HOUSING, CORD CAP AND VOLUTE CASE
Cast iron, Class 30, ASTM A48
RECESSED IMPELLER
Ductile iron, Class 65 ASTM A536
MECHANICAL SEAL OPTIONAL
Double tandem, type 21 carbon and ceramic lower tungsten, carbide
